28x15W led RGBW Full Color SMD RGB LEDs on the front ring LED lifespan: > 50.000h LED refresh frequency: > 400Hz flicker-free
Optic system
Beam Angle: 6/60° Luminous flux: 12900 Lux@5m (full ON - 6°) / 1680 lux@5m (full ON - 60°)
Color system
LED source RGBW Full color Infinite chromatic possibilities
Effects
Linear dimmer 0-100% Motorized zoom Electronic strobo, pulse, random Control with 3 circular sectors Front LED ring with programmable static and dynamic effects CCT: CCT control
Control and programming
3 DMX configurations available: 26/31/43 channels Protocol USITT DMX 512 Master/Slave mode Reset function via DMX Virtual color wheel with 12 color White presets with 9 macros Virtual linear color wheel from 2.700 K to 8.000K
Structure and cabinet
Black metal Housing, and plastic materials with high resistance LCD color graphic display PAN selectable 630°/540°/270° and TILT selectable 270°/180°/90° Mounting points: 2 pairs of 1/4 turn locks Automatic repositioning of PAN and TILT after accidental movement not controlled by control unit 3-poles XLR in/out connection USB port for software update and wireless DMX receiverIP Rating: IP 20 Forced air fan cooling system with electronic control
Power supply
Input Voltage: AC~100-240V 50/60Hz Switching power supply unit Power consumption 390W Power IN/OUT connection with Seetronic Power Twist Power supply cable 1,5 mt included
